TECHNICAL DATA

CONTROLLER:
PLC CONTROL
DISPLAY:
TOUCH SCREEN 12.1",MULTI LANGUAGES
PROGRAM CAPACITY:
UNLIMITED
OPERATION SYSTEM WINDOWS XP
PROGRAMMING:
USER FRIENDLY WITH GRAPHICAL SCREENS
AUTOMATIC CALCULATION OF COIL PROGRAM
DATA MEMORY AND OUTPUT:
USB,CABLE NETWORK,W-LAN,ETHERNET
WINDING SPEED:
UP TO 120 RPM
CORE DRIVE :
SERVO MOTOR 0,8KW/3,3Nm
WIRE PLTCH CONTROL:
FULLY AUTOMATIC PITCH CHANGE
PROGRAMMABLE IN STEPS OF 0,001MM
CORE INDEX & REVERSE CONTROL:
FULLY AUTOMATIC
ACCELERATION & DECELERATION:
FULLY AUTOMATIC
STOPS FOR TAPS:
AUTOMATIC
SECTOR & BANK WINDING CONTROL:
FULLY AUTOMATIC
TAPING OPERATIONS:
FULLY AUTOMATIC
WINDING HEAD DRIVE :
SERVO MOTOR 2,5 KW/11,6Nm
SUPPLY VOLTAGES:
230 (110 AND 240)VOLT, 50 HZ AC
MACHINE SIZE AND WEIGHT:
1300 X 1300 MM; 600 KG NET, 750 KG GROSS

Technical Details:
• Touch Screen 12,1"
• RAM Memory: 1 GB
•  Front Access:1 x USB 2,0
•  Rear Access: 1 x Ethernet 10/100 Mbps
